TASK 53-05-02-250-821
27. INTERNAL - SPECIAL DETAILED: FORWARD GALLEY DOOR SURROUND STRUCTURE DOOR
STOP BACKUP STRUCTURE
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
222 Passenger Compartment - Aft of Control Compartment to Forward Entry Door -
Right
B. Inspection
NOTE: Remove interior panels as required to perform inspection. Door stops are numbered from
the bottom up.
SUBTASK 53-05-02-250-021
(1) Do a High Frequency Eddy Current inspection of the four (4) fastener at each stop location
common to the intercostal tension strap at the forward edge frame at stops #1, #2, #5, #6.
See Doc. D626A001-DTR, DTR check form 53-10-15-2 for alternative inspections.
The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
6, Subject 53-10-98.
END OF TASK
TASK 53-05-02-250-822
28. EXTERNAL - SPECIAL DETAILED: CUTOUT - FWD GALLEY DOOR
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
222 Passenger Compartment - Aft of Control Compartment to Forward Entry Door -
Right
B. Inspection
SUBTASK 53-05-02-250-022
(1) Do a High Frequency Eddy Current inspection around fasteners common to the skin and
chords between stringers S-8R and S-14R at the forward and aft edge frames at STA 291.5
and STA 328.5.
See Doc. D626A001-DTR, DTR check form 53-10-15-4 for alternative inspections.
The NDI method(s) necessary to accomplish the intent of this inspection is contained in the
737 Nondestructive Test Manual (D6-37239). The inspection procedures are contained in Part
6, Subject 53-30-55.
END OF TASK
TASK 53-05-02-250-823
29. INTERNAL - SPECIAL DETAILED: BULKHEAD, STA 294.5
NOTE: This procedure is a scheduled maintenance task.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-02
Page 212
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
