TASK 53-51-21-000-802
4. Center Wing-To-Body Fairing Panel Removal
(Figure 402)
A. References
Reference Title
34-32-11 P/B 401 MARKER BEACON ANTENNA - REMOVAL/INSTALLATION
34-55-11 P/B 401 DME ANTENNA - REMOVAL/INSTALLATION
51-31-00-160-801 Prepare For Sealing (P/B 201)
52-48-42-000-801 Environmental Control Systems (ECS) Access Doors - Removal
(P/B 401)
B. Location Zones
Zone Area
192 Lower Wing-To-Body Fairing - Under Wing Box
193 Lower Wing-To-Body Fairing - Wheel Well
195 Above Wing, Wing-To-Body Fairing - Left
196 Above Wing, Wing-To-Body Fairing - Right
C. Access Panels
Number Name/Location
192AL Underwing Bolt Cover - Forward
192AR Underwing Bolt Cover - Forward
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
192BR ECS Ram Air Inlet Mixing Duct Panel - Forward
192E ECS Under Keel Panel - Forward
192F ECS Under Keel Panel - Middle
192G Sump Drain Access Door
192HL Underwing Bolt Cover - Aft
192HR Underwing Bolt Cover - Aft
192JL Air Conditioning Panel - Aft
192JR Air Conditioning Panel - Aft
192K Air Conditioning Under Keel Panel - Aft
193AL Wheel Well Panel - Forward Outboard
193AR Wheel Well Panel - Forward Outboard
193B Wheel Well Panel - Forward Inboard
193CL Wheel Well Panel - Aft Outboard
193CR Wheel Well Panel - Aft Outboard
193D Wheel Well Panel - Aft Inboard
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 409
D633A101-ILF Oct 15/2014
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
