TASK 53-05-03-210-837
48. INTERNAL - GENERAL VISUAL: AFT PASSENGER COMPARTMENT, STA 663.75 to 1016
(Figure 254)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
241 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Left
242 Aft Passenger Compartment - Station 663.75 to Aft Pressure Bulkhead - Right
B. Access Panels
Number Name/Location
S2401 AFT Passenger Compartment STA 663.75 to 1016
C. Inspection
SUBTASK 53-05-03-010-034
(1) Special Access:
Number Name/Location
S2401 AFT Passenger Compartment STA 663.75 to 1016
NOTE: Remove galleys/lavs. Remove cabin interior as required. Remove/replace insulation
blankets as required.
SUBTASK 53-05-03-210-037
(2) Do a General Visual inspection of the passenger compartment from STA 663.75 to 1016
(except areas around door cutouts), including:
1. Skin panels (skins, frames and stringers), longitudinal lap splices, circumferential skin and
stringer splices (note: inspection includes the circumferential skin and stringer splice at Sta
727I for the -900 models).
2. Window belt structure.
3. STA 663 bulkhead and splices.
4. STA 727 bulkhead.
5. Side strut support frame at STA 706.
6. Main landing gear support frames at STA 695 and 716.
7. Wheel well frame at STA 685.
8. Aft cargo door cutout surround structure (portion in upper lobe).
9. Forward side of STA 1016 bulkhead (chords, pressure web, stiffeners, chord/web
attachments), including vertical fin front spar fittings.
10. Stringer splice fittings and tension bolts at STA 1016.
11. For the -800BCF, frame reinforcements at STA 727B to STA 867 at S-16 to S-17 (Note:
frame reinforcements on LH side only at STA 807 to STA 847), STA 887 frame reinforcements
at S-16 to S-17, and frame fitting and rail support at STA 907 between S-15 and S-17.
SUBTASK 53-05-03-910-051
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-808.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.61
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
