F/O Electrical System Panel, P6-3
Row Col Number Name
E 3 C01321 ENGINE FUEL ENGINE 2 HPSOV CONT
E 4 C01396 ENGINE FUEL ENGINE 2 HPSOV IND
SUBTASK 76-11-03-860-014-F00
(3) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 583
C 7 C01678 WEATHER RADAR RT RIGHT
F/O Electrical System Panel, P6-1
Row Col Number Name
ILF ALL
D 13 C00120 WEATHER RADAR RT
SUBTASK 76-11-03-860-010-F00
(4) Remove the DO-NOT-OPERATE tag from the engine start panel.
END OF TASK
TASK 76-11-03-400-801-F00
4. Control Stand Seal, Spacer, and Retainer Removal
(Figure 402)
A. General
(1) This task provides the instructions on how to remove the control stand seals, spacers and
retainers that are below the lightplates on the control stand.
(2) The retainers hold the seals and spacers in their position on the control stand.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Prepare for the Removal
SUBTASK 76-11-03-010-001-F00
(1) Do this task: Control Stand Lightplate Removal, TASK 76-11-03-000-801-F00.
D. Control Stand Seals, Spacer, and Retainer Removal
SUBTASK 76-11-03-020-003-F00
(1) Remove the left seal [33], the spacer [25], and the seal retainer [31] as follow:
(a) Remove the four screws [32].
(b) Remove the seal retainer [31].
(c) Remove the left seal [33].
(d) Remove the spacer [25].
SUBTASK 76-11-03-020-004-F00
(2) Remove the upper center seal [36], the spacer [26], and the seal retainer [34] as follow:
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 408
D633A101-ILF Jun 15/2019
