ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409, 410, 412,
416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533, 535-537, 541, 542,
552-557, 559-564, 567-569, 571-577, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 671, 672,
686, 691-699, 703, 707-710, 803-813, 821, 822, 831-834, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874,
947, 948, 968-973, 980-999 (Continued)
G. Start lever Installation
SUBTASK 76-11-02-420-001-F00
(1) For engine 1, install the start lever assembly [141] as follows:
(a) Apply grease, D00013 to the inner side of the start lever.
(b) Put the start lever assembly [141] into the control stand.
1) Apply a thin coat of grease, D00013 to each side of the washer [145].
NOTE: The application of the grease will help hold the washer [145] to the start
lever [141].
2) Put the washer [145] in its position on the start lever assembly [141].
3) Put the start lever assembly [141] in its correct position.
4) Move the long control shaft [146] through the washer [145] and the start lever
assembly [141].
5) Put the long control shaft [146] against the dowel.
CAUTION
BE CAREFUL WHEN YOU MOVE THE LONG CONTROL SHAFT. IF THE
NINE WASHERS DO NOT STAY IN THEIR CORRECT POSITION,
DAMAGE CAN OCCUR.
(c) Move the long control shaft and dowel to the right until all of the lever assemblies and
washers [145] are on the long control shaft [146].
(d) Remove the dowel.
(e) Move the start lever assembly [141] forward and aft.
NOTE: The start lever and washer [145] must move freely.
SUBTASK 76-11-02-420-002-F00
(2) For engine 2, install the start lever assembly [142] as follows:
(a) Apply grease, D00013 to the inside of the lever assembly [142].
(b) Put the start lever assembly [142] into the control stand.
1) Apply a thin coat of grease, D00013 to each side of the washer [145].
NOTE: The application of the grease will help hold the washer [145] to the lever.
2) Put the washer [145] in its position on the dowel.
3) Put the start lever assembly [142] in its correct position.
4) Move the long control shaft [146] through the start lever assembly [142].
5) Put the long control shaft [146] against the dowel.
6) Move the long control shaft [146] through the washer [145].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-02
Page 426
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
