MAIN BATTERY CHARGER - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) A removal of the Main Battery Charger.
(2) An installation of the Main Battery Charger.
TASK 24-31-21-000-802-002
2. Main Battery Charger Removal
(Figure 401)
A. General
(1) The M5 Battery Charger is located on the E2-1 equipment rack in the main equipment center.
B. References
Reference Title
20-10-07-000-801 E/E Box Removal (P/B 201)
20-40-12-000-802 ESDS Handling for Metal Encased Unit Removal (P/B 201)
C. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Battery charger 24-31-21-01-007 ILF 301, 304, 308, 310,
314, 315, 317-319, 323,
401, 402, 405, 406, 409,
410, 412, 416, 424, 425,
427-429, 451, 452,
501-504, 507-510,
512-516, 518-520,
523-528, 530-533, 536,
541, 542, 552, 571, 572,
703
24-31-21-01J-015 ILF 101, 151, 156-199,
331-399, 491-500, 535,
537, 553-557, 559-564,
567-569, 573-577, 581,
583, 585, 588-590,
592-599, 601-603, 606,
607, 610-615, 620,
625-627, 671, 672, 686,
691-699, 803-813, 821,
822, 831-838, 841, 842,
851, 852, 854-858,
861-863, 871-874, 947,
948, 968-973, 980-999
D. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-21
Config 2
Page 401
D633A101-ILF Jun 15/2019
