WING-TO-BODY FAIRING - INSPECTION/CHECK
1. General
A. This procedure has one task. The task gives instructions to check the electrical resistance of a wing-
to-body fairing panel.
TASK 53-51-01-765-801
2. Wing-to-Body Fairing Electrical Resistance Check
A. References
Reference Title
53-51-21 P/B 401 WING-TO-BODY FAIRING PANELS -
REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1793 Multimeter - Digital/Analog (or equivalent meter meets task
requirements)
737-600, -700, -800
Part #: 117 Supplier: 89536
Part #: 260-8XPI Supplier: 55026
Part #: 287 Supplier: 89536
Part #: 289 Supplier: 89536
Part #: 87V Supplier: 89536
Part #: FLUKE 27 II Supplier: 89536
Part #: FLUKE-77-4 Supplier: 89536
Opt Part #: 187 Supplier: 89536
Opt Part #: 189 Supplier: 89536
Opt Part #: 21 Supplier: 89536
Opt Part #: 27 Supplier: 89536
Opt Part #: 77 SERIES III Supplier: 89536
Opt Part #: 87 Supplier: 89536
Opt Part #: FLUKE 27 Supplier: 89536
Opt Part #: MODEL 27 Supplier: 89536
C. Consumable Materials
Reference Description Specification
C00767 Coating - Anti-Static Coating BMS10-21 Type III
C00862 Coating - Chemical Conversion - Bonderite
M-CR 600 Aero (Formerly Alodine 600)
D. Location Zones
Zone Area
190 Subzone - Wing-to-Body Fairing
191 Lower Wing-To-Body Fairing - Forward of Wing Box
192 Lower Wing-To-Body Fairing - Under Wing Box
193 Lower Wing-To-Body Fairing - Wheel Well
194 Lower Wing-To-Body Fairing - Aft of Wheel Well
195 Above Wing, Wing-To-Body Fairing - Left
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-01
Page 601
D633A101-ILF Feb 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
