ILF 625-627, 835, 838 (Continued)
F/O Electrical System Panel, P6-3
Row Col Number Name
B 4 C00359 FUEL SPAR VALVE ENG 1
B 5 C00540 FUEL SPAR VALVE IND
E 5 C01320 ENGINE FUEL ENGINE 1 HPSOV CONT
E 6 C01395 ENGINE FUEL ENGINE 1 HPSOV IND
SUBTASK 76-11-02-860-023-F00
(5) For engine 2, Remove the safety tags and close these circuit breakers:
F/O Electrical System Panel, P6-2
Row Col Number Name
B 5 C01313 ENGINE 2 RUN/PWR
B 6 C01318 ENGINE 2 START LEVER CHAN A
B 7 C01319 ENGINE 2 START LEVER CHAN B
C 4 C00154 ENGINE 2 START VALVE
C 5 C01267 ENGINE 2 THRUST REVERSER SYNC LOCK
C 6 C01413 ENGINE 2 THRUST REVERSER INTLK
C 7 C00277 ENGINE 2 THRUST REVERSER CONT
C 8 C01004 ENGINE 2 THRUST REVERSER IND
D 4 C00459 ENGINE 2 IGNITION RIGHT
D 6 C00151 ENGINE 2 IGNITION LEFT
D 7 C01391 ENGINE 2 ALTN PWR CHAN B
D 8 C01315 ENGINE 2 ALTN PWR CHAN A
F/O Electrical System Panel, P6-3
Row Col Number Name
B 3 C00360 FUEL SPAR VALVE ENG 2
E 3 C01321 ENGINE FUEL ENGINE 2 HPSOV CONT
E 4 C01396 ENGINE FUEL ENGINE 2 HPSOV IND
SUBTASK 76-11-02-860-025-F00
(6) For the control stand lighting, remove the safety tags and close these circuit breakers:
Circuit Breaker Panel 5, P8
Row Col Number Name
--- --- C00320 ELEX PANEL LIGHTS FWD
F/O Electrical System Panel, P6-3
Row Col Number Name
C 10 C00284 PANEL & INSTR ELEX PANEL
E. Do a Test of the Start Lever
SUBTASK 76-11-02-210-001-F00
(1) Make sure that the lock tabs are engaged and locked when the lever is in the idle or cutoff
position. The lock tabs on the barrel will be in the same plane as the detent tabs (keyway) and
will not rotate freely.
SUBTASK 76-11-02-710-002-F00
(2) Do this task: Master Dim and Test - Operational Test, TASK 33-18-00-710-802.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-02
Page 446
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
