CAUTION
THE DRIVE LIGHT ON THE P5 PANEL SHOULD GO OFF AFTER THE
ENGINE GETS UP TO IDLE SPEED. IF THE DRIVE LIGHT DOES NOT GO
OFF OR COMES ON WHEN THE ENGINE IS AT OR ABOVE IDLE SPEED,
THE DISCONNECT SWITCH ON THE P5 PANEL MUST BE PUSHED.
FAILURE TO PUSH THE DISCONNECT SWITCH CAN CAUSE DAMAGE
TO THE IDG.
(d) Make sure the number 2 DRIVE light on the P5 panel goes off after number 2 engine
reaches idle speed.
(e) Set the GEN 2 switch on the P5 panel to the ON position.
(f) Make sure the 2 GEN OFF BUS light on the P5 panel goes off.
(g) Make sure the AC meter on the P5 panel shows these values:
1) AC VOLTS = 110-120
2) CPS FREQ = 395-405
(h) Set the GRD PWR switch on the P5 panel to the OFF position.
(i) Make sure both TRANSFER BUS OFF lights on the P5 panel stay off.
F. The Load Test
SUBTASK 24-11-00-410-002
(1) Do the Load Test as follows:
(a) Make sure that these circuit breakers are closed:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406,
409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528,
530-533, 535-537, 541, 542, 552-557, 559-564, 567-569, 571-577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 610-615, 620, 671, 672, 686, 691-699, 703, 707-710, 803-813, 821, 822,
831-833, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-973, 980-999
B 14 C00274 EXTERIOR LIGHTING LANDING RIGHT RETR
B 15 C00271 EXTERIOR LIGHTING LANDING LEFT FIXED
C 14 C00272 EXTERIOR LIGHTING LANDING RIGHT FIXED
C 15 C00273 EXTERIOR LIGHTING LANDING LEFT RETR
Power Distribution Panel Number 1, P91
Row Col Number Name
ILF ALL
C 8 C00768 ELEC HYD PUMP CONTROL SYS B
ILF 496-500, 560-564, 567-569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 625-627, 671, 672, 691-699, 833-835, 838, 948, 968-973, 980-999
D 1 C00827 FUEL BOOST PUMP TANK 1 FWD
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406,
409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-495, 501-504, 507-510, 512-516, 518-520,
523-528, 530-533, 535-537, 541, 542, 552-557, 559, 571-577, 686, 703, 707-710, 803-813, 821,
822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947
D 2 C00827 FUEL BOOST PUMP TANK 1 FWD
ILF 496-500, 560-564, 567-569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615,
620, 625-627, 671, 672, 691-699, 833-835, 838, 948, 968-973, 980-999
D 3 C00828 FUEL BOOST PUMP TANK 2 AFT
