NOSE VORTEX GENERATORS - REMOVAL/INSTALLATION

1. General

A. This procedure contains two tasks.

(1) The first task is the removal of the nose vortex generators.

(2) The second task is the installation of the nose vortex generators.

TASK 53-31-11-000-801

2. Remove the Nose Vortex Generators

(Figure 401)

A. Tools/Equipment

NOTE: When more than one tool part number is listed under the same "Reference" number, the

tools shown are alternates to each other within the same airplane series. Tool part numbers

that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.

Reference Description

COM-2481 Sealant Removal Tool (meets BSS7384 requirements)

737-700, -800

Part #: 1-6390-A Supplier: 63318

Part #: 10810 Supplier: $0855

Part #: 10811 Supplier: $0855

Part #: 10812 Supplier: $0855

Part #: 234350 Supplier: 92108

Part #: 235072 Supplier: 92108

Part #: 235073 Supplier: 92108

Part #: 235074 Supplier: 92108

Part #: 235075 Supplier: 92108

Part #: 235076 Supplier: 92108

Part #: 235077 Supplier: 92108

Part #: 235078 Supplier: 92108

Part #: 235079 Supplier: 92108

Part #: 235080 Supplier: 92108

Part #: 235081 Supplier: 92108

Part #: 311/03 Supplier: F6892

Part #: 311/14 Supplier: F6892

Part #: 311/25 Supplier: F6892

Part #: 311/37 Supplier: F6892

Part #: 411B60 Supplier: 3DN12

Part #: 411B90 Supplier: 3DN12

Part #: DAD5013 Supplier: 7RKH2

Part #: DFD5019 Supplier: 7RKH2

Part #: SCD5019 Supplier: 7RKH2

Part #: ST982LF-9 Supplier: 62176

Part #: TS1275-4 Supplier: 1DWR5

B. Location Zones

Zone Area

211 Flight Compartment - Left

212 Flight Compartment - Right

737-600/700/800/900

AIRCRAFT MAINTENANCE MANUAL

53-31-11

Page 401

D633A101-ILF Jun 15/2019

EFFECTIVITY

ILF 491-500, 559-564, 567-569, 577, 581, 583, 585,

588-590, 592-599, 601-603, 606, 607, 610-615, 620,

625-627, 671, 672, 691-699, 832-838, 841, 842, 851,

852, 857, 858, 874, 947, 948, 968-973, 980-999
