SUBTASK 53-14-01-020-008
(2) Remove the aft access panel [18].
G. Top Access Panels Removal
SUBTASK 53-14-01-020-001
(1) Remove the top access panels [4] and the spring assemblies [20]:
(a) Remove the bolts [1], bolts [5] and bolts [6].
(b) Remove the O-ring seal washers [3] and the washers [2].
(c) Remove the top access panel [4] and the spring assembly [20].
(d) If necessary, remove the spring assembly [20].
1) Remove the bolts [8], the washers [9] and the nuts [10] from the spring
assembly [20] and top access panel [4].
2) Remove the spring [7], the filler [12] and the plate [13].
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-14-01
Page 402
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
