SUBTASK 24-31-11-010-001-001
(4) To get access to the main equipment center, do this step:
Open this access panel:
Number Name/Location
117A Electronic Equipment Access Door
ILF 562, 588, 592-596, 833, 834
SUBTASK 24-31-11-010-005
(5) Remove the access cover on top of the J39 shield to get access to the circuit breakers.
ILF 562, 588, 592-596, 686, 707-710, 833, 834, 854-856, 861-863, 871-874
SUBTASK 24-31-11-860-004-001
(6) Open this circuit breaker and install safety tag:
Battery Shield, J9
Row Col Number Name
A 4 C00142 BATTERY CHARGER
SUBTASK 24-31-11-010-002-001
(7) Get access to the forward cargo area through the forward cargo door.
(a) Remove the forward bulkhead liner to get access to the battery
F. Battery Removal
SUBTASK 24-31-11-020-001-001
(1) Remove the battery [1] as follows:
(a) Disconnect the battery connector from the battery.
(b) Disconnect the electrical connector from the battery.
(c) Remove the six bolts [2] and washers [3] from the battery mounting brackets.
(d) Slide the skid plate, equipment, SPL-1633 under the battery.
NOTE: The skid plate is used so that the battery will not touch the capstrip just below it.
CAUTION
DO NOT LET THE BATTERY TOUCH THE CAPSTRIP JUST BELOW THE
BATTERY MOUNTING RACK. IF THE BATTERY TOUCHES THE
CAPSTRIP, IT CAN SCRATCH IT AND CAUSE DAMAGE TO THE SEAL
THAT FORMS WHEN THE CLOSE-OUT PANEL IS INSTALLED.
(e) Slide the battery out from the battery rack to the forward cargo area.
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Config 1
Page 402
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 562, 588, 592-596, 686, 707-710, 833, 834,
854-856, 861-863, 871-874
