DC GENERATION SYSTEM - MAINTENANCE PRACTICES
1. General
A. This procedure has these tasks:
(1) DC Generation System Deactivation
(2) DC Generation System Activation
TASK 24-31-00-040-801
2. DC Generation System - Deactivation
(Figure 201)
A. General
(1) This procedure removes electrical power from the DC Generation System.
B. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
D. Procedure
SUBTASK 24-31-00-010-001
(1) Open this access panel:
Number Name/Location
117A Electronic Equipment Access Door
SUBTASK 24-31-00-860-004
WARNING
BE CAREFUL WHEN YOU OPEN OR CLOSE CIRCUIT BREAKERS IN THE
P91 AND P92 PANELS WHILE THE PANELS HAVE POWER. ELECTRICAL
SHOCK CAN CAUSE INJURIES TO PERSONNEL.
(2) Open these circuit breakers and install safety tags:
Battery Shield, J9
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
A 3 C01209 AUX BAT CHARGER
ILF ALL
A 4 C00142 BATTERY CHARGER
A 5 C01340 BATTERY BUS
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-00
Page 201
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
