TASK 80-11-01-610-801-F00
3. Starter Servicing (Oil Fill)
(Figure 301)
A. General
(1) This task provides the instructions on how to service the starter with oil.
(a) The Preferred Method uses a tool installed in the magnetic plug housing.
1) Do this procedure after you install the starter on the engine.
(b) The Alternate Method removes the magnetic plug housing to gravity fill the starter.
1) If the service tools are not available, do the alternate method before you install the
starter on the engine.
(2) For this task, use the same type of oil that is used in the engine oil tank.
(3) After you do this task, it is not necessary to fill the starter again unless you remove the starter
or drain the oil. The starter is supplied engine oil from the accessory gearbox.
(4) The starter is on the forward side of the accessory gearbox.
B. References
Reference Title
71-11-02-010-801-F00 Open the Fan Cowl Panels (P/B 201)
71-11-02-410-801-F00 Close the Fan Cowl Panels (P/B 201)
80-11-01-360-801-F00 Starter Magnetic Plug Housing Packing Replacement (P/B 801)
80-11-01-400-801-F00 Starter Installation (P/B 401)
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-2464 Adapter - Starter Drain, Engine
737-600, -700, -800
Part #: DB75-108 Supplier: 97484
STD-4051
Dispenser - Pressurized Oil Source
D. Consumable Materials
Reference Description Specification
D00599 [CP2442] Oil - Engine CFM CP2442
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 306
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
