(Continued)
Zone Area
212 Flight Compartment - Right
G. Thrust levers Installation
SUBTASK 76-11-01-420-001-F00
(1) For engine 1, install the thrust lever assembly [141] as follows (Figure 407):
(a) Apply grease, D00013 to the inside of the thrust lever.
(b) Put the lever assembly [141] into the control stand.
1) Apply a thin coat of grease, D00013 to each side of the washer that you will install.
NOTE: The application of grease, D00013 will help to hold the washers to the
thrust lever.
2) Make sure that the washers [145] are in their position on the dowel between the
thrust levers.
3) Hold the thrust lever assembly [141] in the correct position.
4) Move the long control shaft [146] through the thrust lever.
5) Move the long control shaft [146] through the washers [145].
6) Put the long control shaft [146] against the right side end of the dowel set,
SPL-2409.
7) Move the thrust lever forward and aft.
NOTE: The levers and washers [145] must move freely when you move them from
the dowel to the long control shaft.
CAUTION
BE CAREFUL WHEN YOU MOVE THE CONTROL SHAFT. IF THE
WASHERS DO NOT STAY IN THEIR CORRECT POSITION, DAMAGE
CAN OCCUR.
(c) Move the long control shaft [146] and dowel to the right until all of the lever assemblies
and washers [145] are on the long control shaft [146].
(d) Remove the dowel.
SUBTASK 76-11-01-420-002-F00
(2) For engine 2, install the thrust lever assembly [142] as follows (Figure 407):
(a) Apply grease, D00013 to the inside of the thrust lever assembly [142].
1) Apply a thin coat of grease, D00013 to each side of the washers [145] that you will
install.
NOTE: The application of grease, D00013 will help to hold the washers to the
thrust lever.
(b) Put the thrust lever assembly [142] into the control stand.
NOTE: Make sure that the connecting rod and the wire guide are in the correct install
position.
1) Make sure that the washers [145] are in their position on the long control shaft [146]
between the two thrust levers.
NOTE: Two washers [145] should be between the two thrust levers.
2) Hold the thrust lever assembly [142] in the correct position.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-01
Page 427
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
