BATTERY CONNECTOR - INSPECTION/CHECK
1. General
A. This procedure contains this task:
(1) Battery Connector Inspection
B. The main battery, M6, is located below the E3 equipment rack in the main equipment area.
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409, 410, 412,
416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533, 535-537, 541, 542,
552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599, 601-603, 606, 607, 610-615, 620,
625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832, 835-838, 841, 842, 851, 852, 857, 858, 947, 948,
968-973, 980-999
C. The auxiliary battery, M3054, is located just forward of the main battery.
D. The main battery must be removed before you can remove the auxiliary battery. You do not have to
remove the auxiliary battery to replace the main battery.
ILF ALL
TASK 24-31-11-200-801
2. Battery Connector Inspection
(Figure 601)
A. References
Reference Title
20-10-44-400-801 Lockwire, Cotter Pins, and Lockrings - Installation (P/B 401)
20-50-11 P/B 201 STANDARD TORQUE VALUES - MAINTENANCE PRACTICES
24-22-00-860-812 Remove Electrical Power (P/B 201)
24-22-00-860-813 Supply External Power (P/B 201)
31-25-00 P/B 501 CLOCKS - ADJUSTMENT/TEST
49-11-00-860-801 APU Starting and Operation (P/B 201)
49-11-00-860-802 APU Usual Shutdown (P/B 201)
FIM 24-31 TASK 801 P5-13 ELEC Light Message BITE Procedure
SWPM 20-30-11 Standard Wiring Practices Manual
SWPM 20-62-25 Standard Wiring Practices Manual
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-12292 Gage Tool - Battery Inspection
737-600, -700, -800
Part #: J24016-1 Supplier: 81205
C. Consumable Materials
Reference Description Specification
G02479 Lockwire - MS20995CY20, Copper - 0.020
Inch (0.508 mm) Diameter
NASM20995
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Page 601
D633A101-ILF Jun 15/2019
