ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319,
323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518, 524,
531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831,
832, 836, 837, 841, 842, 851, 852, 854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
(Continued)
(Continued)
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999; ILF 567, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GENERATION CONTROL
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
E 15 C01680 NGS ALT PWR
SUBTASK 47-43-02-860-001
(2) Remove the DO-NOT-OPERATE tags from the L PACK and R PACK selector switches on the
P5 panel.
(a) Put the L PACK and R PACK selector switches to the AUTO position.
SUBTASK 47-43-02-740-001
(3) Do this task to do a check of the thermal switch: Ground Operation of the Nitrogen Generation
System, TASK 47-00-00-800-801.
(a) Make sure the test is good and the BITE message for the thermal switch [2] does not
show.
(b) With the NGS pressurized, use the leak detector, G50135, to do a check for leaks around
the thermal switch [2].
(c) Use a clean cotton wiper, G00034, to remove the leak detector, G50135.
(d) Repair the leaks that you find.
I. Put the Airplane Back to the Usual Condition
SUBTASK 47-43-02-410-001
(1) Close these access panels:
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
192CR ECS Access Door
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-43-02
Page 408
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
To Next Page
