SUBTASK 53-51-21-020-008
(2) Do these steps to remove the applicable fairing panels:
NOTE: Hold the fairing panel until all the fasteners have been removed.
NOTE: Identify the fasteners to install them in the same locations.
(a) Zone 194:
1) Remove the fasteners for access panel [57]:
Number Name/Location
194AL Aft Wing To Body Fairing Panel
2) Remove the fasteners for access panel [50]:
Number Name/Location
194AR Aft Wing To Body Fairing Panel
3) Remove the fasteners for access panel [56]:
Number Name/Location
194BL Flap Track Lubrication Panel - Aft
4) Remove the fasteners for access panel [51]:
Number Name/Location
194BR Flap Track Lubrication Panel - Aft
5) Remove the fasteners for access panel [64]:
Number Name/Location
194CL Aft Wing To Body Fairing Panel
6) Remove the fasteners for access panel [52]:
Number Name/Location
194CR Aft Wing To Body Fairing Panel
7) Remove the fasteners for access panel [55]:
Number Name/Location
194DL Aft Wing To Body Fairing Panel
8) Remove the fasteners for access panel [53]:
Number Name/Location
194DR Aft Wing To Body Fairing Panel
9) Remove the fasteners for access panel [54]:
Number Name/Location
194E Aft Wing To Body Fairing Panel
10) Remove the fasteners for access panel [58]:
Number Name/Location
194FL Aft Wing To Body Fairing Panel
a) If required, remove the Auxiliary Power Unit (APU) drain mast
(TASK 28-25-07-020-801).
11) Remove the fasteners for access panel [62]:
Number Name/Location
194FR Aft Wing To Body Fairing Panel
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-51-21
Page 422
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
