TASK 24-31-00-440-801
3. DC Generation System - Activation
(Figure 201)
A. General
(1) This procedure adds electrical power to the DC Generation System.
B. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
C. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
D. Procedure
SUBTASK 24-31-00-860-006
WARNING
BE CAREFUL WHEN YOU OPEN OR CLOSE CIRCUIT BREAKERS IN THE
P91 AND P92 PANELS WHILE THE PANELS HAVE POWER. ELECTRICAL
SHOCK CAN CAUSE INJURIES TO PERSONNEL.
(1) Remove the safety tags and close these circuit breakers:
Battery Shield, J9
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
A 3 C01209 AUX BAT CHARGER
ILF ALL
A 4 C00142 BATTERY CHARGER
A 5 C01340 BATTERY BUS
Power Distribution Panel Number 1, P91
Row Col Number Name
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 402, 405, 406, 409,
410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510, 512-516, 518-520, 523-528, 530-533,
535-537, 541, 542, 552-557, 559-561, 563, 564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599,
601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
E 3 C00922 AUX BAT CHGR
Power Distribution Panel Number 2, P92
Row Col Number Name
ILF ALL
E 1 C00809 BAT CHGR
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-00
Page 205
D633A101-ILF Jun 15/2019
