Boeing 737-600 - Pageblock 80-11-01;601 - STARTER - INSPECTION;CHECK; Task 80-11-01-200-802-F00 - Starter Inspection; Subtask 80-11-01-860-038-F00; Subtask 80-11-01-860-039-F00

STARTER - INSPECTION/CHECK
1. General
A. This procedure has two tasks:
(1) Starter Inspection
(2) Starter Magnetic Plug Inspection.
TASK 80-11-01-200-802-F00
2. Starter Inspection
(Figure 601)
A. General
(1) This task provides the instructions to examine the starter for oil leaks, sheared housing bolts
and also to examine the magnetic plug on the starter.
(2) The starter is on the forward side of the accessory gearbox.
B. References
Reference Title
71-11-02-010-801-F00 Open the Fan Cowl Panels (P/B 201)
71-11-02-410-801-F00 Close the Fan Cowl Panels (P/B 201)
80-11-01-000-801-F00 Starter Removal (P/B 401)
80-11-01-360-801-F00 Starter Magnetic Plug Housing Packing Replacement (P/B 801)
80-11-01-360-802-F00 Starter Housing Bolts Replacement (P/B 801)
80-11-01-400-801-F00 Starter Installation (P/B 401)
C. Location Zones
Zone Area
411 Engine 1 - Engine
421 Engine 2 - Engine
D. Prepare for the Inspection
SUBTASK 80-11-01-860-038-F00
(1) For Engine 1, open this circuit breaker and install a safety tag:
CAPT Electrical System Panel, P18-2
Row Col Number Name
B 8 C01103 ENGINE 1 START VALVE
SUBTASK 80-11-01-860-039-F00
(2) For Engine 2, open this circuit breaker and install a safety tag:
F/O Electrical System Panel, P6-2
Row Col Number Name
C 4 C00154 ENGINE 2 START VALVE
SUBTASK 80-11-01-010-019-F00
(3) Do this task: Open the Fan Cowl Panels, TASK 71-11-02-010-801-F00.
E. Starter Inspection
SUBTASK 80-11-01-210-002-F00
(1) Examine the starter gear housing and the exhaust housing for oil leaks.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
80-11-01
Page 601
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
