THRUST LEVERS - REMOVAL/INSTALLATION
1. General
A. This procedure has two tasks:
(1) Thrust Levers Removal
(2) Thrust Levers Installation.
TASK 76-11-01-010-801-F00
2. Thrust Levers Removal
(Figure 401, Figure 402, Figure 403, Figure 404, Figure 405, Figure 406, Figure 407, and Figure 408)
A. General
(1) This task gives you instructions on how to remove the thrust levers from the aisle control stand.
B. References
Reference Title
25-11-01-000-801 Captain's and First Officer's Seat Removal (P/B 401)
27-41-00-820-801 Stabilizer Control Cable and Chain - Adjustment (P/B 501)
27-51-00-040-801 Trailing Edge Flap System Deactivation (P/B 201)
27-62-00-820-801 Speed Brake Control Lever Adjustment (P/B 501)
76-11-03-000-801-F00 Control Stand Lightplate Removal (P/B 401)
76-11-03-400-801-F00 Control Stand Seal, Spacer, and Retainer Removal (P/B 401)
76-11-03-400-803-F00 Control Stand Cover and Stop Removal (P/B 401)
C. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-1585 Kit - Rigging Pin
737-600, -700, -800
Part #: F70207-109 Supplier: 81205
SPL-2409 Dowel Set - Thrust Lever, Control Stand
737-600, -700, -800
Part #: F80195-1 Supplier: 81205
SPL-2411 Tool Set - Control Stand Disassembly
737-600, -700, -800
Part #: C76002-26 Supplier: 81205
D. Consumable Materials
Reference Description Specification
G50314 Tape - Masking BAC5034-4 Type VII
Class 2
E. Location Zones
Zone Area
112 Area Forward of Nose Landing Gear Wheel Well
211 Flight Compartment - Left
212 Flight Compartment - Right
