F
W
D
FWD
A
A
[65] NUT
[63] WASHER
[66] SCREW
[67] CHAIN
GUARD
[62] SCREW
[61] WASHER
[63] WASHER
[64] SCREW
G02915 S0006583046_V2
Chain Guard Assembly Installation
Figure 403/76-11-01-990-803-F00
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-01
Page 414
D633A101-ILF Oct 15/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
