TASK 47-32-04-400-801
5. NGS Filter Assembly - Installation
(Figure 402)
A. References
Reference Title
20-30-80-910-801 General Cleaning of Metal (Series 80) (P/B 201)
47-00-00-790-801 Leak Check of the Nitrogen Generation System (P/B 601)
SWPM 20-20-00 ELECTRICAL BONDING PROCESSES
SWPM 20-20-10 Standard Wiring Practices Manual
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
COM-1550 Bonding Meters - Approved, Intrinsically Safe (Approved for use in
Class I, Divisions I & II hazardous (classified) locations. Outside
these hazardous locations, COM-614 can be used in lieu of
COM-1550).
737-600, -700, -800
Part #: 620LK Supplier: 1CRL2
Part #: M1 Supplier: 3AD17
Part #: T477W (C15292) Supplier: 01014
Opt Part #: M1B Supplier: 3AD17
C. Consumable Materials
Reference Description Specification
C00852 Compound - Antiseize, Molybdenum
Disulfide-Petrolatum
MIL-PRF-83483
G50136 Compound - Corrosion Inhibiting, Non-drying
Paste
BMS3-38
D. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 NGS filter assembly 47-32-04-01-010 ILF 402, 451, 452, 503,
504, 508-510, 514, 516,
523-528, 541, 568, 569,
573-577, 581, 583, 585,
588-590, 592-599,
601-603, 606, 607,
610-615, 620, 625-627,
691-699, 832-835, 838,
854, 856, 971, 980-999
47-32-04-01-190 ILF 606, 607, 611-615,
620, 625-627, 695-699,
833-835, 838
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-32-04
Page 415
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
