F. Prepare for the removal
SUBTASK 24-41-11-860-001
(1) Do this task: Remove Electrical Power, TASK 24-22-00-860-812.
SUBTASK 24-41-11-010-001
(2) Open this access panel if it is closed:
Number Name/Location
114AR External Power Receptacle Door
SUBTASK 24-41-11-010-002
(3) Remove External Power Plug from the receptacle, if it is installed.
SUBTASK 24-41-11-930-001
WARNING
MAKE SURE YOU PUT A DO-NOT-OPERATE TAG ON THE EXTERNAL
POWER RECEPTACLE. FAILURE TO DO THIS CAN CAUSE INJURY TO
PERSONS.
(4) Attach a DO-NOT-OPERATE tag to the external power receptacle.
SUBTASK 24-41-11-010-003
(5) Open access panel on forward right hand side of nose gear wheel well, to get access to the
back of the receptacle.
G. External Power Receptacle Removal
SUBTASK 24-41-11-020-001
(1) Remove the electrical leads from the receptacle:
(a) Remove the screw [11], from back of terminal cover.
(b) Remove the nuts [9] and washers [8] that hold the terminal cover.
(c) Remove the cover assembly [10].
(d) Attach an identification tag to each lead.
(e) Remove the six nuts [7], lockwashers [6], and washers [5] that hold the six electrical
leads.
(f) Remove the electrical leads from the studs.
SUBTASK 24-41-11-020-002
(2) Remove the receptacle [1] per the steps that follow:
ILF 401, 405, 406, 409, 410, 412, 416, 424, 425 PRE SB 737-24-1198
(a) Remove the four nuts [4], four washers [3], and four bolts [2] that hold the receptacle to
the pan.
NOTE: This step works best with two people, one outside the airplane and one inside the
wheel well access. However if only one person is available, you can put tape
over the bolts to prevent them from falling out when the nuts are removed.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-41-11
Page 402
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 686; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323,
331-399, 401, 402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 496,
498-504, 507-510, 512-516, 518-520, 523-528, 530-533, 535-537, 541, 542,
552-557, 560-562, 567-569, 571-577, 581, 583, 585, 671, 672, 703, 707-710,
803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-971, 973 PRE SB 737-24-1198
