TASK 76-11-03-420-801-F00
3. Control Stand Lightplate Installation
(Figure 401)
A. General
(1) This task provides the instructions on how to install a lightplate on the control stand.
B. References
Reference Title
27-41-00-700-801 Stabilizer Manual Trim and Trim Indicator Test (P/B 501)
27-51-00-820-802 Trailing Edge Flap Drive System Adjustment (P/B 501)
C. Location Zones
Zone Area
211 Flight Compartment - Left
212 Flight Compartment - Right
D. Control Stand Lightplate Installation
SUBTASK 76-11-03-420-001-F00
CAUTION
BE VERY CAREFUL WHEN YOU INSTALL THE LIGHTPLATES AND THE
CONTROL STAND COMPONENTS. DAMAGE TO THE LIGHTPLATES,
SWITCHES, NUTPLATES, WIRE BUNDLES AND THE FINISH ON THE PARTS
CAN OCCUR.
(1) Install the wires to the lightplate [1], the lightplate [4], the lightplate [6] or the lightplate [9] as
follows:
(a) Install two washers [22].
(b) Put the two terminal lugs on the lightplate studs.
(c) Install the two lockwashers [23] and two nuts [24].
SUBTASK 76-11-03-420-002-F00
CAUTION
USE CARE WHEN YOU TIGHTEN THE SCREWS ON THE LIGHTPLATES.
DAMAGE TO THE LIGHTPLATES CAN OCCUR IF YOU OVER TIGHTEN THE
SCREWS.
(2) Install the applicable the lightplate [1], the lightplate [4], the lightplate [6] or the lightplate [9] on
the cover assemblies as follows:
(a) Install the stabilizer trim lightplate [1] for the Captain as follows
1) Install the two screws [10]
2) Adjust the position of the lightplate [1] (TASK 27-41-00-700-801).
(b) Install the flap lever indicator lightplate [4] as follows:
1) Install the two screws [5].
2) Adjust the position of the lightplate [4] (TASK 27-51-00-820-802).
(c) Install the stabilizer trim lightplate [6] for the First Officer as follows.
1) Install the two screws [7].
2) Adjust the position of the lightplate [6] (TASK 27-41-00-700-801).
(d) Install the speed brake lightplate [9].
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 406
D633A101-ILF Oct 15/2018
