Boeing 737-600 - Page 2107

B
FWD
[24] NUT
[23] LOCKWASHER
[22] WASHER
TERMINAL LUG
(EXAMPLE - TWO LOCATIONS
ON EACH LIGHTPLATE)
LIGHTPLATE
G29097 S0006583077_V2
Control Stand Lightplate Installation
Figure 401/76-11-03-990-801-F00 (Sheet 2 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-03
Page 405
D633A101-ILF Jun 15/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
