3) Tighten the bolt to 150 in-lb (16.9 N·m) – 170 in-lb (19.2 N·m).
4) Install the left bolt [8] and spacer.
5) Do a check of the run-on torque of the bolt.
6) Tighten the bolt to 150 in-lb (16.9 N·m) – 160 in-lb (18.1 N·m) more than the run-on
torque.
SUBTASK 76-11-02-200-001-F00
(14) Do a visual check of the assembly as follows:
(a) Move each control through its usual range.
(b) Make sure that the electrical bundles do not touch parts.
SUBTASK 76-11-02-410-002-F00
(15) Install the stabilizer trim switch panel [10] for the trim stabilizer as follows:
(a) Put the stabilizer trim switch panel [10] on the control stand.
(b) Install the four screws [9].
SUBTASK 76-11-02-410-007-F00
(16) Install these seals and retainers (TASK 76-11-03-400-802-F00):
(a) The right seal retainer and the right seal
(b) The center seal retainer and the center seal
(c) The left seal retainer and the left seal.
SUBTASK 76-11-02-410-008-F00
(17) Install these covers and stops TASK 76-11-03-400-804-F00:
(a) The right cover and the right side cover assembly
(b) The center cover
(c) The forward thrust stop and the aft thrust stop
(d) The stabilizer trim horn cutout switch knob [6] for the stabilizer trim horn cutout switch.
SUBTASK 76-11-02-410-009-F00
(18) Install these lightplates (TASK 76-11-03-420-801-F00):
(a) The first officers stabilizer trim lightplate.
(b) The flap lever lightplate.
SUBTASK 76-11-02-010-006-F00
(19) Install the access covers on the control stand as follows:
(a) Install the left upper side panel [1] with four screws [2].
(b) Install the left lower side panel [5] with five screw [2].
(c) Install the right upper side panel [3] with four screws [2].
(d) Install the right lower side panel [4] with four screws [2].
