TASK 53-05-03-210-828
31. INTERNAL - GENERAL VISUAL: AREA UNDER WING-TO-BODY FAIRING (above wing)
(Figure 234,Figure 235)
NOTE: This procedure is a scheduled maintenance task.
A. Location Zones
Zone Area
195 Above Wing, Wing-To-Body Fairing - Left
196 Above Wing, Wing-To-Body Fairing - Right
B. Access Panels
Number Name/Location
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
C. Inspection
SUBTASK 53-05-03-010-025
(1) Open these access panels:
Number Name/Location
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
SUBTASK 53-05-03-210-028
(2) Do a General Visual inspection of the area under above-wing wing-to-body fairing, including
skin panels, circumferential skin splices, and stringer 18 strap at side of body.
SUBTASK 53-05-03-910-035
(3) 737-6789 Basic Task Description, AMM Task 51-05-01-210-806.
SUBTASK 53-05-03-410-025
(4) Close these access panels:
Number Name/Location
195AL Wing To Body Fairing - Left Side
195AR Wing To Body Fairing - Right Side
195BL Wing To Body Fairing - Left Side
195BR Wing To Body Fairing - Right Side
195CL Wing To Body Fairing - Left Side
195CR Wing To Body Fairings - Right Side
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.8
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
