ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
SUBTASK 47-21-07-650-001
(9) Drain fuel from the NEADS line (TASK 47-21-00-700-802.
ILF 402, 451, 452, 494-500, 503, 504, 509, 510, 514, 523-528, 541, 560-564, 567-569, 574-577, 581,
583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 832-835,
838, 856-858, 947, 948, 968-973, 980-999; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315,
317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 501, 502, 507, 508, 512,
513, 516, 518, 531-533, 535-537, 542, 552-556, 571-573, 686, 703, 707-710, 803-813, 821, 822, 831,
836, 837, 841, 842, 851, 852, 854, 855, 861-863, 871-874 POST SB 737-47-1002 OR POST SB
737-47-1003 OR POST SB 737-47-1015; ILF 491-493, 515, 519, 520, 530, 557, 559 POST SB
737-47-1002 OR POST SB 737-47-1015
H. Remove the Flame Arrestor
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
SUBTASK 47-21-07-030-002
(1) Disconnect the dielectric hose [6] from the flame arrestor [1].
(a) Put a protective cover on the dielectric hose [6].
ILF 402, 451, 452, 494-500, 503, 504, 509, 510, 514, 523-528, 541, 560-564, 567-569, 574-577, 581,
583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 832-835,
838, 856-858, 947, 948, 968-973, 980-999; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315,
317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 501, 502, 507, 508, 512,
513, 516, 518, 531-533, 535-537, 542, 552-556, 571-573, 686, 703, 707-710, 803-813, 821, 822, 831,
836, 837, 841, 842, 851, 852, 854, 855, 861-863, 871-874 POST SB 737-47-1002 OR POST SB
737-47-1003 OR POST SB 737-47-1015; ILF 491-493, 515, 519, 520, 530, 557, 559 POST SB
737-47-1002 OR POST SB 737-47-1015
SUBTASK 47-21-07-941-001
(2) Go into the fuel tank (TASK 28-11-00-910-802).
CAUTION
MAKE SURE THAT YOU DO NOT PUSH OR PULL THE FQIS
COMPONENTS IN THE FUEL TANK. DAMAGE TO FQIS COMPONENTS
CAN EASILY OCCUR.
(a) Go to the flame arrestor [1] location.
NOTE: The flame arrestor [1] is on the rear spar adjacent to the fuel boost pump.
SUBTASK 47-21-07-490-001
(3) Disconnect the NEADS tube [5] from the flame arrestor [1].
(a) Put a protective cover on the NEADS tube [5].
SUBTASK 47-21-07-100-001
(4) Do these steps to remove the flame arrestor [1]:
(a) Use the sealant removal tool, SPL-768, (sealant removal tool, COM-2481. or equivalent)
to remove the sealant from the nut [3] in the center tank.
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-21-07
Page 405
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 451, 452, 494-500, 503, 504, 509, 510, 514, 523-528, 541, 560-564, 567-569, 574-577, 581, 583, 585,
588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 671, 672, 691-699, 832-835, 838, 856-858, 947,
948, 968-973, 980-999; ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 501, 502, 507, 508, 512, 513, 516, 518, 531-533, 535-537, 542,
552-556, 571-573, 686, 703, 707-710, 803-813, 821, 822, 831, 836, 837, 841, 842, 851, 852, 854, 855, 861-863,
871-874 POST SB 737-47-1002 OR POST SB 737-47-1003 OR POST SB 737-47-1015; ILF 491-493, 515,
519, 520, 530, 557, 559 POST SB 737-47-1002 OR POST SB 737-47-1015
