(g) Align the holes on the clamp [70], spacer [75]and clamp [71] (View J, Figure 402
(Sheet 11)).
(h) Install the screw [74], washers [73], and nut [72] to the clamp [70], spacer [75] and
clamp [71].
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
SUBTASK 47-11-01-760-003
(11) Use an intrinsically safe approved bonding meter, COM-1550, to measure the resistance
between the jumper tab [61] and ASM mount [49] (SWPM 20-20-00).
(a) Make sure that the resistance is 0.008 ohm (8 milliohms) or less.
SUBTASK 47-11-01-760-004
(12) Use an intrinsically safe approved bonding meter, COM-1550, to measure the resistance
between the NEADS duct [27] and tube [46] though the bonding jumper [41] (SWPM 20-20-00)
(a) Make sure that the resistance is 0.010 ohm (10 milliohms) or less.
SUBTASK 47-11-01-760-005
(13) Use an intrinsically safe approved bonding meter, COM-1550, to measure the resistance
between the NEADS duct [27] and tube [46] though the bonding jumper [45] (SWPM 20-20-00)
(a) Make sure that the resistance is 0.010 ohm (10 milliohms) or less.
J. Air Separation Module Post-Installation Test
SUBTASK 47-11-01-860-008
(1) Do these steps to prepare for the operational test:
(a) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310,
314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451,
501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GEN CONT
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627,
691-699, 833-835, 838, 980-999; ILF 567, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GENERATION CONTROL
