SUBTASK 47-42-03-430-004
CAUTION
KEEP THE OXYGEN SENSOR AND THE INLET TUBE CLEAN AND FREE OF
CONTAMINATION. CONTAMINATION CAN CAUSE DAMAGE TO THE
OXYGEN SENSOR.
(4) Connect the oxygen sensor inlet tube to the oxygen sensor [5] and tighten the coupling nut [3].
SUBTASK 47-42-03-430-002
(5) Install the screw [4] and washer [6] to attach the bonding jumper [2].
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999
SUBTASK 47-42-03-765-001
(6) Do a check of the electrical bond between the oxygen sensor [5] and the structure with an
intrinsically safe approved bonding meter, COM-1550 (SWPM 20-20-10).
(a) Make sure the resistance is 0.010 ohm (10 milliohms) or less.
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
SUBTASK 47-42-03-760-002
(7) Do a check of the electrical bond between the bonding jumper tab and the mounting frame with
an intrinsically safe approved bonding meter, COM-1550 (SWPM 20-20-10).
(a) Make sure that the resistance is 0.0009 ohm (0.9 milliohm) or less.
SUBTASK 47-42-03-760-003
(8) Do a check of the electrical bond between the oxygen sensor [5] and the structure with an
intrinsically safe approved bonding meter, COM-1550 (SWPM 20-20-10).
(a) Make sure that the resistance is 0.008 ohm (8 milliohms) or less.
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
SUBTASK 47-42-03-030-009
(9) Connect the electrical connector.
I. Operational Test of the Oxygen Sensor
SUBTASK 47-42-03-700-001
(1) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GEN CONT
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-42-03
Page 408
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
