(a) Remove Conditioned Air Supplied by a Cooling Pack, TASK 21-00-00-800-804.
(b) Remove Pressure from the Pneumatic System, TASK 36-00-00-860-806.
SUBTASK 47-00-00-080-004
(2) If installed, disconnect the sense line, SPL-11507, from the GSE O2 test port.
(a) Install the cap on the GSE O2 test port.
SUBTASK 47-00-00-080-002
(3) If used, remove the oxygen analyzer, COM-7456.
SUBTASK 47-00-00-741-014
(4) Do a check of the duct pressure on the dual duct pressure gage:
(a) Make sure the L and R duct pressure is 0 psig (0 kPa).
SUBTASK 47-00-00-741-015
(5) Do this task: APU Usual Shutdown, TASK 49-11-00-860-802, if necessary.
SUBTASK 47-00-00-410-007
(6) Close these access panels:
Number Name/Location
192BL ECS Ram Air Inlet Mixing Duct Panel - Forward
192CL ECS Access Door
192DR ECS High Pressure Access Door
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-00-00
Page 507
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
