(c) The forward thrust stop and the aft thrust stop.
SUBTASK 76-11-01-410-008-F00
(22) Install the stabilizer trim horn cutout switch knob [6] for the stabilizer trim horn cutout switch.
SUBTASK 76-11-01-410-005-F00
(23) Install these seals and retainers (TASK 76-11-03-400-802-F00):
(a) The right seal retainer and the right seal.
(b) The center seal retainer and the center seal.
(c) The left seal retainer and the left seal.
SUBTASK 76-11-01-410-006-F00
(24) Install these lightplates (TASK 76-11-03-420-801-F00):
(a) The first officers stabilizer trim lightplate.
(b) The flap lever lightplate.
SUBTASK 76-11-01-410-007-F00
(25) Do this task: Captain's and First Officer's Seat Installation, TASK 25-11-01-400-801.
H. Put the Airplane Back to Its Usual Condition
SUBTASK 76-11-01-860-007-F00
(1) Remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 583
C 7 C01678 WEATHER RADAR RT RIGHT
F/O Electrical System Panel, P6-1
Row Col Number Name
ILF ALL
D 13 C00120 WEATHER RADAR RT
SUBTASK 76-11-01-860-010-F00
(2) For Engine 1, remove the safety tags and close these circuit breakers:
CAPT Electrical System Panel, P18-2
Row Col Number Name
A 1 C00458 ENGINE 1 IGNITION RIGHT
A 3 C00153 ENGINE 1 IGNITION LEFT
A 4 C01390 ENGINE 1 ALTN PWR CHAN B
A 5 C01314 ENGINE 1 ALTN PWR CHAN A
B 1 C01316 ENGINE 1 START LEVER CHAN A
B 2 C01317 ENGINE 1 START LEVER CHAN B
B 3 C01312 ENGINE 1 RUN/PWR
B 4 C01003 ENGINE 1 THRUST REVERSER IND
B 5 C00276 ENGINE 1 THRUST REVERSER CONT
B 6 C01412 ENGINE 1 THRUST REVERSER INTLK
B 7 C01266 ENGINE 1 THRUST REVERSER SYNC LOCK
B 8 C01103 ENGINE 1 START VALVE
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
CFM56 ENGINES (CFM56-7)
76-11-01
Page 432
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
