SUBTASK 76-11-02-010-010-F00
(3) Remove the stabilizer trim horn cutout switch knob [6].
SUBTASK 76-11-02-010-011-F00
(4) Remove forward thrust stop and the aft thrust stop (TASK 76-11-03-400-803-F00):
SUBTASK 76-11-02-010-012-F00
(5) Move the right side cover assembly forward and carefully lay it on the front of the stand.
SUBTASK 76-11-02-020-014-F00
(6) Remove the center cover assembly(TASK 76-11-03-400-803-F00):
SUBTASK 76-11-02-010-005-F00
(7) Get access to the start levers in the control stand as follows :
(a) Remove the bolt [8] and the right stabilizer trim wheel [7].
NOTE: Keep the left stabilizer trim wheel attached so you can turn the assembled levers
during removal.
(b) Remove the spacer.
NOTE: The spacer is not installed with the countersunk head bolt.
(c) Remove the four screws [2] and the left upper side panel [1].
(d) Remove the five screws [2] and the left lower side panel [5].
(e) Remove the four screws [2] and the right upper side panel [3].
(f) Remove the four screws [2] and the right lower side panel [4].
(g) Remove the four screws [9].
(h) Apply masking tape, G50314 to prevent damage to the surface of the stabilizer trim
switch panel [10].
(i) Move the stabilizer trim switch panel [10] from the control stand to the mat.
SUBTASK 76-11-02-020-001-F00
(8) Disconnect the flap indicator assembly on the right side of the control stand as follows:
(a) Remove the nut [16], the washer [14], the washer [15], and the bolt [17] from the lower
end of the link assembly [13].
(b) Use a temporary wire tie to safety the link assembly to the control stand.
SUBTASK 76-11-02-020-002-F00
(9) Disconnect the flap lever position synchro assembly on the right side of the control stand as
follows:
(a) Remove the nut [18] and the bolt [19] from the lower end of the link assembly [12].
(b) Use a wire tie to temporarily safety the link assembly to the control stand.
SUBTASK 76-11-02-020-003-F00
(10) Disconnect the stabilizer trim controls as follows:
(a) Turn the left trim wheel until you find the link in the trim chain.
NOTE: This will help if it becomes necessary to disconnect the chain during installation.
