Boeing 737-600 - Section 47-31 - NGS CONTROL SYSTEM; Subject 47-31-01 - NITROGEN GENERATION SYSTEM CONTROLLER; Pageblock 47-31-01;401 - NITROGEN GENERATION SYSTEM CONTROLLER - REMOVAL;INSTALLATION; Task 47-31-01-000-801 - Nitrogen Generation System Controller Removal

NITROGEN GENERATION SYSTEM CONTROLLER - REMOVAL/INSTALLATION
1. General
A. This procedure has these tasks:
(1) Nitrogen Generation System Controller Removal
(2) Nitrogen Generation System Controller Installation
TASK 47-31-01-000-801
2. Nitrogen Generation System Controller Removal
(Figure 401)
A. General
(1) This nitrogen generation system controller is referred to at the controller [1] in this task.
B. References
Reference Title
25-52-17-000-801 Forward Cargo Compartment Aft Bulkhead Liner - Removal
(P/B 401)
C. Location Zones
Zone Area
122 Forward Cargo Compartment - Right
125 Air Conditioning Distribution Bay - Left
126 Air Conditioning Distribution Bay - Right
212 Flight Compartment - Right
D. Access Panels
Number Name/Location
821 Forward Cargo Door
E. Prepare for the Removal
SUBTASK 47-31-01-865-001
(1) Open these circuit breakers and install safety tags:
CAPT Electrical System Panel, P18-3
Row Col Number Name
ILF 402, 452, 509, 510, 523, 525-528, 576, 577, 971; ILF 101, 151, 156-199, 301, 304, 308, 310, 314,
315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507,
508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672,
686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GEN CONT
ILF 568, 569, 581, 583, 585, 588-590, 592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699,
833-835, 838, 980-999; ILF 567, 973 POST SB 737-47-1003
D 17 C01657 NITROGEN GENERATION CONTROL
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590, 592-599, 601-603,
606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999; ILF 101, 151, 156-199, 301,
304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405, 406, 409, 410, 412, 416, 424, 425, 427-429,
451, 501-504, 507, 508, 512-514, 516, 518, 524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567,
571-575, 671, 672, 686, 703, 707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852,
854-858, 861-863, 871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
E 15 C01680 NGS ALT PWR
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-31-01
Page 401
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 402, 452, 509, 510, 523, 525-528, 568, 569, 576, 577, 581, 583, 585, 588-590,
592-599, 601-603, 606, 607, 610-615, 620, 625-627, 691-699, 833-835, 838, 971, 980-999;
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401, 405,
406, 409, 410, 412, 416, 424, 425, 427-429, 451, 501-504, 507, 508, 512-514, 516, 518,
524, 531-533, 535-537, 541, 542, 552-556, 560-562, 567, 571-575, 671, 672, 686, 703,
707-710, 803-813, 821, 822, 831, 832, 836, 837, 841, 842, 851, 852, 854-858, 861-863,
871-874, 947, 948, 968-970, 972, 973 POST SB 737-47-1003
