E. Expendables/Parts
AMM Item Description AIPC Reference AIPC Effectivity
1 Battery 24-31-11-01-020 ILF 101, 151, 156-199,
301, 304, 308, 310, 314,
315, 317-319, 323,
331-399, 401, 402, 405,
406, 409, 410, 412, 416,
424, 425, 427-429, 451,
452, 491, 492, 501-504,
507-510, 512-516,
518-520, 523-528,
530-533, 535-537, 541,
542, 552-557, 559,
571-577, 703, 803-813,
821, 822, 831, 832, 836,
837
F. Location Zones
Zone Area
117 Electrical and Electronics Compartment - Left
118 Electrical and Electronics Compartment - Right
121 Forward Cargo Compartment - Left
122 Forward Cargo Compartment - Right
211 Flight Compartment - Left
212 Flight Compartment - Right
G. Access Panels
Number Name/Location
117A Electronic Equipment Access Door
H. Battery Installation
SUBTASK 24-31-11-420-002-002
(1) Install the auxiliary battery [1] as follows:
(a) Put the skid plate, equipment, SPL-1633 in position as shown in (Figure 401).
CAUTION
DO NOT LET THE BATTERY TOUCH THE CAPSTRIP IMMEDIATELY
BELOW THE BATTERY-MOUNTING-RACK. IF THE BATTERY TOUCHES
THE CAPSTRIP, THEN IT CAN SCRATCH IT. THIS CAN CAUSE SEAL
DAMAGE THAT FORMS WHEN YOU INSTALL THE CLOSE-OUT PANEL.
(b) Have two persons hold each of the battery handles and lift the battery onto the skid plate.
Slide the battery into position.
NOTE: Make sure the terminals point left.
(c) Remove the skid plate.
NOTE: You may have to tilt the battery back some to remove the skid plate.
(d) Install the six bolts [2] and washers [3] on the battery mounting brackets.
(e) Connect the electrical connector to the battery.
(f) Connect the battery connector to the battery.
1) Safetywire the battery connector with 0.02 in. (0.508 mm) diameter MS20995CY20
lockwire, G02479, (TASK 20-30-51-910-801).
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-31-11
Config 2
Page 409
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 101, 151, 156-199, 301, 304, 308, 310, 314, 315, 317-319, 323, 331-399, 401,
402, 405, 406, 409, 410, 412, 416, 424, 425, 427-429, 451, 452, 491-504, 507-510,
512-516, 518-520, 523-528, 530-533, 535-537, 541, 542, 552-557, 559-561, 563,
564, 567-569, 571-577, 581, 583, 585, 589, 590, 597-599, 601-603, 606, 607,
610-615, 620, 625-627, 671, 672, 691-699, 703, 803-813, 821, 822, 831, 832,
835-838, 841, 842, 851, 852, 857, 858, 947, 948, 968-973, 980-999
