SUBTASK 76-11-02-020-007-F00
(14) Release the start lever assemblies as follows:
(a) Find the bent tab on the lockwasher [143].
(b) Use the lockwasher removal tool from tool set, SPL-2411 to bend the tab out of the notch
in the nut [144].
(c) Put one control shaft wrench from tool set, SPL-2411 on the left side of the long control
shaft [146] to hold it in position.
(d) Put the control shaft nut wrench from tool set, SPL-2411 to remove the nut [144] from the
long control shaft [146].
(e) Remove the nut [144] from the long control shaft [146].
(f) Remove and discard the lockwasher [143].
SUBTASK 76-11-02-020-008-F00
(15) For Engine 1, remove the start lever assembly [141] as follows:
CAUTION
BE CAREFUL WHEN YOU INSERT THE DOWEL. IF THE NINE WASHERS
DO NOT STAY IN THEIR CORRECT POSITION, DAMAGE CAN OCCUR.
(a) Put the dowel set, SPL-2409 against the right side of the long control shaft [146].
(b) Hit lightly (carefully tap) on the dowel.
NOTE: This is to move the long control shaft off the control levers.
1) Move the dowel until the start lever assembly [141] is on the dowel.
NOTE: Do not move the long control shaft from the position it is in. More movement
will let the washer falls.
(c) Hold the start lever assembly [141]and remove the dowel from the start lever.
1) Stop the dowel movement when you can lift the start lever.
(d) Remove the start lever assembly [141] through the top of the control stand.
(e) Remove the washer [145] from between the start lever and the control stand frame.
NOTE: Make sure that the washer does not fall into the control stand.
(f) Install the start lever assembly [141] before you remove the start lever assembly [142] for
engine 2.
SUBTASK 76-11-02-020-009-F00
(16) For Engine 2, remove the start lever assembly [142] as follows:
CAUTION
BE CAREFUL WHEN YOU INSERT THE DOWEL. IF THE NINE WASHERS
DO NOT STAY IN THEIR CORRECT POSITION, DAMAGE CAN OCCUR.
(a) Put the dowel set, SPL-2409 against the right end of the long control shaft [146].
