(a) Disconnect the electrical connector [3] from the overtemperature shutoff valve [1].
(b) Remove the screw [12], washer [13], and nut [14] to disconnect the bonding jumper [2].
1) Keep the screw [12], washer [13], and nut [14] for the installation.
(c) Disconnect the coupling [7] from between the air supply duct [5] and the overtemperature
shutoff valve [1].
(d) Remove the sleeve [6] from between the air supply duct [5] and the overtemperature
shutoff valve [1].
1) Discard the two o-rings [4].
(e) Hold the overtemperature shutoff valve [1] in its position.
(f) Disconnect the clamp [8] from between the overtemperature shutoff valve [1] and the air
separation module [10].
1) Discard the o-ring [9].
(g) Remove the overtemperature shutoff valve [1].
(h) Put a protective cover on the inlet port for the air separation module [10], and on the air
supply duct [5].
END OF TASK
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
47-11-04
Page 403
D633A101-ILF Oct 15/2019
