Boeing 737-600 - Page 123

F
W
D
A
A
A
A
A-A
[6] SCREW
(2 LOCATIONS)
THROUGH LEAD
STRAPS
(4 LOCATIONS)
[9] TERMINAL BLOCK
[7] WASHER
(2 LOCATIONS)
[3] WASHER
(2 LOCATIONS)
[2] SCREW
(2 LOCATIONS)
[5] CAPTIVE WASHER NUT
(4 LOCATIONS)
PHASE LEAD
(4 LOCATIONS)
[4] TERMINAL BLOCK
COVER
[1] IDG
(EXAMPLE)
TERMINAL STUD
[8] SQUARE
WASHER
[9] TERMINAL
BLOCK
THROUGH
LEAD
2293135 S0000519265_V5
IDG Terminal Block Installation
Figure 401/24-11-62-990-801
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-11-62
Page 403
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
