A
FWD
A
MPD ITEM
53-430-00
VERTICAL FIN REAR
SPAR FITTING
STA 1156
BULKHEAD
UPPER HORIZONTAL
DECK
STA 1088
BULKHEAD
HORIZONTAL
STABILIZER HINGE
FITTINGS AND BOLTS
LONGITUDINAL
LAP SPLICE
LOWER
HORIZONTAL
DECK
SKIN PANEL
STRINGER
INSPECTION HOLE
IN LOWER DECK
OPENING IN BULKHEAD
FOR ACCESS TO
INSPECTION AREA
INSPECTION AREA
STABILIZER TORSION BOX AND APU COMPARTMENTS
(LEFT SIDE SHOWN, RIGHT SIDE OPPOSITE)
(APU PLENUM, APU, AND FIREWALLS REMOVED)
STABILIZER TORSION BOX
AND APU COMPARTMENTS
2097200 S0000441491_V2
INTERNAL-GENERAL VISUAL: STABILIZER TORSION BOX COMPARTMENT AND APU COMPARTMENT
Figure 256/53-05-03-990-857
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-05-03
Page 298.73
D633A101-ILF Jun 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
