D
E
DAMS FOR HOSE-OUT OPTION
SEALS AT STATIONS 380 AND 520 BULKHEAD
FRAME CHORD
STRINGER
BULKHEAD
ALUMINUM SEAL PLATE
(STA 520 ONLY)
PACKING COMPOUND
AND PRESSURE SEAL
FRAME
ALUMINUM
SEAL PLATE
J72208 S0000174893_V2
Lower Lobe Structure
Figure 202/53-11-37-990-803 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-11-37
Page 212
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
