Boeing 737-600 - Page 177

1
D
1
(EXAMPLE)
5mm-WRENCH
APPROXIMATE 15˚
USE 5mm-WRENCH TO HOLD THE SPACER NUTS IN PLACE WHILE
LOOSENING THE SCREWS ON THE ELECTRICAL CONNECTOR.
FAILURE TO USE WRENCH COULD RESULT IN DAMAGE TO HARDWARE.
[2] BOLT
[3] WASHER
(6 LOCATIONS)
ELECTRICAL
CONNECTOR
K21959 S0006566193_V3
Main Power Breaker Installation
Figure 401/24-21-41-990-801 (Sheet 3 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
24-21-41
Page 405
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
