Boeing 737-600 - Page 1801

E
E
D
F
W
D
[14] BOLT
(26 LOCATIONS)
[3] O-RING SEAL
WASHER
[2] WASHER
WASHER AND O-RING
SEAL WASHER
(EXAMPLE)
[15] ACCESS
PANEL
WASHER AND O-RING
SEAL WASHER
(26 LOCATIONS)
[16] GASKET
SEAL
FORWARD SIDE
ACCESS PANEL
1560402 S0000288610_V3
Nose Wheel Well Access Panels Removal/Installation
Figure 401/53-14-01-990-802 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-14-01
Page 405
D633A101-ILF Feb 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
