1
2
INBD
2
1
4.00 INCH
(101.6 mm)
PER BMS 8-2 CLASS 1 GRADE A TYPE 13
PER BMS 8-346 CLASS 4 GRADE A TYPE II
FIBERGLASS REINFORCED
POLYESTER
INSULATION BLANKET
FLOOR PANEL
INSTALLATION
MOISTURE BARRIER TAPE
4.00 INCH
(101.6 mm)
2786064 S0000632176_V2
Floor Panel Sealing
Figure 402/53-21-00-990-808 (Sheet 3 of 4)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-21-00
Page 408
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
