SEALANT
(IF APPLICABLE)
JOINT TAPE
FLOOR PANEL
INSERT
1.00 INCH
(25.4 mm) (MIN)
3.00 INCHES
(76.2 mm) (MAX)
4.00 INCHES
(101.6 mm)
SEAM
TAPE
WATERSEAL
TAPE
FLOOR
PANEL
WATERSEAL SPLICE
(EXAMPLE)
JOINT TAPE INSTALLATION
(EXAMPLE)
FLOOR
PANEL
2179324 S0000481177_V2
Water Seal Tape Application
Figure 801/53-21-00-990-802 (Sheet 1 of 7)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-21-00
Page 808
D633A101-ILF Oct 15/2015
