D
B
U
O
T
A-A
D
B
U
O
T
B-B
0.03 ±0.01 INCH
SEAL PLATE
TRACK
CORNER
PLATE
TIE-BAR
RUB GUIDE
SEAL PLATE
SEAL PLATE
INBOARD TRACK
OUTBOARD
TRACK STRIP
PROTECTIVE
MYLAR TAPE
H20834 S0006581035_V2
Front Spar Sliding Seal Installation
Figure 401/53-31-31-990-801 (Sheet 2 of 3)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-31-31
Config 1
Page 407
D633A101-ILF Jun 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF 301, 304, 308, 310, 314, 315, 317-319, 323, 331, 405,
406, 409, 410, 416, 424, 427-429, 451, 501-504, 507, 508,
512-516, 518-520, 524, 531-533, 535-537, 541, 542, 552,
571, 572, 703, 707-710, 803 PRE SB 737-53-1252
