A
B
A
NOSE
RADOME
(OPEN)
NOSE RADOME OPEN
(SOME PARTS NOT SHOWN)
[1] SUPPORT RODS
(3 LOCATIONS)
STOWED POSITION
[1] SUPPORT RODS
(3 LOCATIONS)
OPEN POSITION
2140372 S0000464416_V2
Nose Radome Open/Close Procedure
Figure 201/53-52-00-990-806 (Sheet 1 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-00
Page 202
D633A101-ILF Oct 15/2015
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
