Boeing 737-600 - Page 1933

A
1
FWD
1
A
NOSE RADOME
LOCATION
MARKINGS
NOSE
RADOME
TAPE FOR
MARKINGS
NOSE RADOME
BOOT
NOSE
RADOME
REMOVE LOCATION MARKINGS AFTER
INSTALLATION OF THE RADOME BOOT
1501368 S0000273433_V2
Radome Boot Installation
Figure 202/53-52-00-990-804
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-00
Page 209
D633A101-ILF Jun 15/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
