A-A
A
A
PROBE CROSS SECTION
CIRCULAR BRAID
ELECTRODES
SPONGE RUBBER
2.5 ±0.1 INCH
(63.5 ±2.5 mm)
CONNECT MEASURING
EQUIPMENT AT THESE
POINTS
SPONGE RUBBER
0.25 ±0.01 INCH
(6.35 ±0.25 mm)
2337246 S0000532389_V2
ST895A-3 Resistivity Probe
Figure 707/53-52-00-990-810
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-52-00
Page 721
D633A101-ILF Oct 15/2018
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
