Boeing 737-600 - Page 2005

A
A
F
W
D
[1] TAILCONE
HORIZONTAL
STABILIZER
[5] RUB STRIP
[4] SCREW
(4 LOCATIONS)
[3] SCREW
(4 LOCATIONS)
TAILCONE
[11] LOWER TRACK
ASSEMBLY
414768 S0000136219_V3
Tailcone Removal / Installation
Figure 401/53-53-00-990-801 (Sheet 1 of 2)
737-600/700/800/900
AIRCRAFT MAINTENANCE MANUAL
53-53-00
Page 411
D633A101-ILF Oct 15/2019
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ILF ALL
